2020 FORD F550XL regular cab, GVWR19500, 6.7L V8 Power Stroke Turbo Diesel engine or 7.3L Gas engine, 6-Sp automatic transmission, Hydraulic brakes, spring suspension, steel wheels, 3-passenger grey vinyl interior, A/C, AM/FM/Bluetooth radio, power windows and doors.



URBAN FORESTRY UNIT WITH ALUMINUM CHIPPER BOX

The Urban Forestry Unit is the only Class 5 bucket truck with a chipper box in the tree care industry with a reach of 50 feet and it's now available with a lightweight aluminum chipper box. Those in the tree care industry already love the Urban Forestry Unit because of its size and weight and now its getting even lighter. The lighter weight means less damage to yards and property making this an ideal solution for those in the urban forestry industry, said Loren Top, Dur-A-Lift's national sales manager. Height to bottom of platform: 45 Working height: 50 Side reach: 30 Stowed travel height: 11.3 Basket capacity: 350# Articulating arm travel: 0 to 82 Main boom travel: -25 to 78 Extension travel: 122.5



STANDARD FEATURES CONTROLS

Proportional controls Lower controls with override located at the turntable Engine start/stop from the basket Individual control levers HYDRAULIC SYSTEM Rated pressure is 2200 PSI Operating pressure is 2000 PSI Opecenter hydraulic system 180 rotating basket



MECHANICAL SYSTEM

Telescoping and articulating boom action Offset main boom reduces travel height Shear ball rotation driven Fully enclosed worm gear box Non-continuous rotation 46KV category C on insulated models 24 x 24 x 42 basket 110V outlet at upper controls DTAXS OPTIONS Single hand joystick upper control Outrigger or torsiobars 12-volt DC backup Fixed basket position (side or end) Basket offered various sizes and configurations Basket liner 50 kV DTAX Main boom fiberglass inserts DTAX Chassis isolator art boom fiberglass insert DTAX Continuous rotation Tool trays of various sizes Basket and control cover Upper and lower hydraulic tool circuits Special paint color



CHIPPER BODY FEATURES

7.5 Length, 54 Side Height 7.5 Cubic Yard Capacity 3/16 Thick Sides, 1/4 Thick Floor Single Swing Rear Gate with Robust Latch Greaseless Hinges Pruning Compartment Superior Top Ventilation

2020 Ford F550XL Dur-A-Lift DTAX-45FP Urban Forestry Truck

SKU: F550DTAX45FPS
Color: Silver
Fuel
GVWR
Located at:
  • * $1949/ Mo for 84 MO with $20000 down not all buyers will qualify please call for more information
